Solid Carbide End Mill 10mm 10x30-38x80xD10

Solid Carbide End Mill 10mm 10x30-38x80xD10

$74.05 - $74.05
$74.05
$74.05 - $74.05
$74.05


D1 (Cutting diameter): 10mm
D3 (Undercut diameter): 9.6mm
L2 ( Length of cut): 30mm
L3 (Length of undercut): 38 mm
L1 (Total length): 80mm
D2 (Shank diameter): 10mm
Z (Number of cutting edges): 4


  • Optimized chip chambers for a large chip volume
  • Adapted roughing teeth for small chips
  • For roughing under HPC conditions

 * MADE IN GERMANY *



Cooling: air-cooled, dry, water min, water max

Tolerance: e8

Coating: BetaUni Iron

Applications: X, Y, Helical

Features:  Extended Trochoidal Cutting, High Performance Cutting, Universal Machining, Unequal Tooth Pitch, Trimming, Full Slot, Serrated Edge, 3XD, Center Cutting, Corner Bevel

item code: 171005
